Modified sine wave 240VAC UPS Power Inverter IG3110E Series 600VA, 900VA, 1400VA, 1800VA
Contact Person : Ella
Phone Number : 0755-81495850
WhatsApp : +8613682556888
| Minimum Order Quantity : | 2PCS | Price : | 100USD |
|---|---|---|---|
| Packaging Details : | Standard Exported Cartons and Pallets | Delivery Time : | Within 15-30days after receiving your 30% TT deposit |
| Payment Terms : | L/C, T/T, Western Union | Supply Ability : | 5000PCS Per Month |
| Place of Origin: | China | Brand Name: | SOROTEC |
|---|---|---|---|
| Certification: | CE,ROHS,RSO9000 | Model Number: | SSP3118C1 1-5KVA |
|
Detail Information |
|||
| Product: | Off Grid Solar Power Inverter | Wave Form: | Pure Sine Wave Output Inverter |
|---|---|---|---|
| Transformer: | Not | Capacity: | 1000va / 800w |
| Design: | High Frequency Half Bridge | Protection: | Overload,overcharge,output Short Circuit And So On |
| Selectable Input Voltage Range: | Yes | Application: | Fridge,Aircondition,computer,TV,solar Power System |
| Dimension: | 95*240*316mm | Weight: | 5.0kg |
| Service: | OEM Service | Warranty: | 1 Year |
| Maintenance Service: | Allowed | Accessories: | Input Wires And Output Plug |
| Highlight: | solar power inverter for home,home power inverter |
||
Product Description
1000va 800w Small Power High Frequency Pure Sine Wave Solar Energy Inverter for Air Conditional-SSP3118C1 Series Solar Power Inverter
Key Features:
1. Pure sine wave output solar power inverter
2. Cold start function and Remote panel available
3. Auto restart while AC is recovering
4. Overload and short circuit protection
5. Compatible to mains voltage or generator power
6. Selectable charging current based on applications
7. Configurable AC/Solar input priority via LCD setting
8. Built-in MPPT/PWM (Optional) solar charge controller
9. Intelligent battery charger design for optimized battery performance
10.Reliable Parallel operation with up to 6 units only available for 4KVA/5KVA
11. Selectable input voltage range for home appliances and personal computers
Protection Function:
Protection for low battery voltage,over load,output short circuit and over- temperature Restrain surge interference,eliminate noise,protection for thunder striking,provide the reliable power to the home appliances.
Typical Applications:
Supply the reliable long back up time power for the home appliances and office appliances Solar power systems etc.
Technical Descriptions for SSP3118C1 1-5KVA Off-Grid Solar Power Inverter
| MODEL | C1 1K-1250 | C1 2K-2450 | C1 3K-2450 | C1 4K-4850 | C1 5K-4850 |
| Rated Power | 1000VA / 800W | 2000VA/1600W | 3000VA / 2400W | 4000VA / 3200W | 5000VA / 4000W |
| INPUT | |||||
| Voltage | 230 VAC | ||||
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) | ||||
| Frequency Range | 50 Hz/60 Hz (Auto sensing) | ||||
| OUTPUT | |||||
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5 % | ||||
| Surge Power | 2000VA | 4000VA | 6000VA | 8000VA | 10000VA |
| Efficiency (Peak) | 90% | 93% | |||
| Transfer Time | 10 ms (For Personal Computers) 20 ms (For Home Appliances) | ||||
| Waveform | Pure sine wave | ||||
| BATTERY | |||||
| Battery Voltage | 12 VDC | 24 VDC | 48 VDC | ||
| Floating Charge Voltage | 13.5 VDC | 27 VDC | 54 VDC | ||
| Overcharge Protection | 15.5 VDC | 31 VDC | 60 VDC | ||
| SOLAR CHARGER & AC CHARGER | |||||
| Maximum PV Array Open Circuit Voltage | 50VDC | 60VDC | 105VDC | ||
| Standby Power Consumption | 1 W | 2 W | 2W | ||
| Maxmum Solar Charge Current | 50A | 50A | 50 A | ||
| Maximum AC Charge Current | 20 A | 30 A | 60 A | ||
| Maximum Charge Current | 50 A | 50 A | 110 A | ||
| PHYSICAL | |||||
| Dimension, D x W x H (mm) | 95 x 240 x 316 | 100 x 272 x 355 | 120 x 295 x 468 | ||
| Net Weight (kgs) | 5 | 6.4 | 6.9 | 9.8 | 9.8 |
| OPERATING ENVIRONMENT | |||||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | ||||
| Operating Temperature | 0°C - 55°C | ||||
| Storage Temperature | -15°C - 60°C | ||||
